Model:CB01.010(Plastic case, lower mount) CB01.050(Plastic case, center back mount) CB06.010(Steel case, lower mount) CB06.050(Steel case, center back mount)
CSHERUN is leading China manufacturer of Plastic Capsule Pressure Gauge, offers of gauges crafted from copper alloy、plastic/steel case. Our Plastic Capsule Pressure Gauge are specially designed for use with gaseous, dry media in protected environments. They are ideal for applications in the medical field, vacuum technology, environmental monitoring, laboratory settings, as well as for content measurement and filter monitoring.
You can rest assured to buy Plastic Capsule Pressure Gauge from our factory and we will offer you the best after-sale service and timely delivery. The advanced Plastic Capsule Pressure Gauge, manufactured in China, is primarily employed for measuring gas pressure and offers capabilities for micro-pressure measurement and over-pressure protection within certain limits. Crafted with high-quality copper alloy and available in plastic or steel casing materials, this gauge boasts a front-mounted zero point setting for ease of use.
The scale range of the Plastic Capsule Pressure Gauge extends from 0 to 2.5 mbar up to 0 to 600 mbar, providing precise and reliable measurements. The China (CSHERUN) Plastic Capsule Pressure Gauge is specifically designed for use with gaseous, dry media in protected environments. It is ideal for applications in the medical field, vacuum technology, environmental monitoring, laboratory settings, as well as for content measurement and filter monitoring. With its robust construction and precise measurement capabilities, this gauge ensures reliable performance across a diverse range of industries and applications.
Applications
● For gaseous, dry media
● Pressure gauge for use in a protected environment
● Medical, vacuum, environmental, laboratory technology, for contents measurement and filter monitoring
Special features
● Zero point setting in front
● Scale ranges from 0 … 2.5mbar to 0 … 600mbar
Description
Design
EN 837-3
Nominal size in mm
50, 63
Accuracy class
1.6
Zero point setting with adjustment screw
In front, after opening the window
Scale ranges
0 … 2.5 to 0 … 600mbar
Pressure limitation
Steady: Full scale value
Fluctuating: 0.9 x full scale value
Short time: 1.3 x full scale value
Permissible temperature
Ambient: -20 … +60 °C
Medium: -20 … +100 °C
Temperature effect
On deviation from the reference conditions at the measuring system: ≤ ±0.6 % per 10 °C [≤ ±0.6 % per 18 °F] of full scale value
Ingress protection per IEC/EN 60529
IP32
IP54
Process connection
Copper alloy
NS 63: G ¼ B (male)
NS 100, 160: G ½ B (male)
Connection location
Bottom mount
Centre back mount
Capsule element
Copper alloy
Movement
Copper alloy
Dial
Aluminium
Pointer
Aluminium, black
Case
Plastic
Steel
Window
PC
Options
■ Other process connection
■ Other range colour
