CSHERUN is a professional ChinaPressure Gauge Per EN 837-1 With Mounted Diaphragm Seal manufacturer and supplier.You can rest assured to buy CSHERUNPressure Gauge Per EN 837-1 With Mounted Diaphragm Seal from our factory and we will offer you the best after-sale service and timely delivery.CSHERUN Pressure Gauge Per EN 837-1 With Mounted Diaphragm Seal has excellent performance, is very reliable and durable, has high measurement accuracy, and its practical value has been widely recognized in the industry.
CSHERUNPressure Gauge Per EN 837-1 With Mounted Diaphragm Seal is very popular in the industry due to its key features and benefits, as follows:
●EN 837-1 Compliance: Ensures superior accuracy, reliability, and safety. The gauge is rigorously tested to withstand overload conditions, including leak-tightness under 2.5x overload for 24 hours, guaranteeing performance in critical processes.
●Diaphragm Seal Technology: Incorporates a high-grade 316 stainless steel diaphragm seal, providing exceptional corrosion resistance and efficient pressure transmission. The fully welded construction ensures long-term durability and leak-free operation.
●Flange Connection with Flush Diaphragm: Designed for seamless integration with pipeline systems, the flush diaphragm eliminates crevices, facilitating easy cleaning and minimizing the risk of media entrapment. Ideal for applications involving viscous, crystallizing, or corrosive media.
●For aggressive, highly viscous, crystalline or hot media
● Process industry
● Machine building and plant construction
● Flange with a flush welded diaphragm
● Robust, all welded design
● Universal application
Versatile Applications: Widely used in chemical, petroleum, metallurgy, and power industries. Excels in environments with corrosive media, high-vibration conditions, or non-clogging pressure systems.
Why Choose ThisPressure Gauge Per EN 837-1 With Mounted Diaphragm Seal?
This CSHERUN Pressure Gauge Per EN 837-1 With Mounted Diaphragm Seal is built to deliver precise measurements, exceptional durability, and reliable performance in the harshest industrial conditions. Its advanced design ensures compatibility with a wide range of media and processes, making it a trusted choice for engineers and technicians worldwide.
Contact us today to learn more about how thisPressure Gauge Per EN 837-1 With Mounted Diaphragm Seal can enhance your industrial operations.
|
Design
|
Pressure gauge with bourdon tube per EN837-1, diaphragm seal with flange connection, flush diaphragm
|
|
|
Nominal size(NS)
|
100 |
|
|
Accuracy class
|
1.0 |
|
|
Pressure limitation
|
Steady: Full scale value Fluctuating: 0.9 x full scale value Short time: 1.3 x full scale value |
|
|
Permissible temperature range |
Medium: -10 ... 150 °C [14 ... 302 °F] Ambient: 10 ... 40 °C [50 ... 104 °F] Storage: 10 ... 60 °C [50 ... 140 °F] |
|
|
Ingress protection |
IP65 per IEC/EN 60529 |
|
|
Material
|
Wetted Diaphragm: Stainless steel 1.4435 [316L] Diaphragm seal: Stainless steel 1.4404 [316L]
Non-wetted Dial, pointer: Aluminium Case: Stainless steel 1.4301 [304] Window: Laminated safety glass |
|
|
Level of cleanliness of wetted parts |
Oil and grease free per ASTM G93-03 level F and ISO 15001 (< 1,000 mg/m²) |
|
|
System fill fluid |
Silicone oil KN 2 for general applications |
|
|
Gauge pressure |
||||
|
0...1 [0 ... 15] |
0 ... 1.6 [0 ... 20] |
0 ... 2.5 [0 ... 30] |
0 ... 4 [0 ... 60] |
0 ... 6 [0 ... 100] |
|
0 ... 10 [0 ... 160] |
0 ... 16 [0 ... 200] |
0 ... 25 [0 ... 300] |
0 ... 40 [0 ... 600] |
|
|
Vacuum and +/- measuring range |
||
|
-1 ... +5 [-30 inHg ... +70] |
-1 ... +9 [-30 inHg ... +130] |
-1 ... +10 [-30 inHg ... +145] |
