CSHERUN's Welding Pressure Gauge & Pressure Gauge Wholesale combines a bourdon tube and bimetal thermometer, crafted from high-quality copper alloy. It measures both pressure and temperature simultaneously, suited for various applications. The thermometer integrates seamlessly via a stem, and the valve allows easy unscrewing without draining the system. It offers flexible display options and impressive scale ranges (0-16 bar pressure, 0-150°C temperature), ideal for heating systems and combi-boilers. CSHERUN provides robust, versatile, and user-friendly precision measurement instruments, focusing on reliability, cost-effectiveness, and innovation to meet global customer needs.
● For equipment and plants for welding, cutting and allied processes
● Design per ISO 5171
● Pressure relief in case back
● Reliable and cost-effective
|
Design |
ISO 5171 |
|
|
Nominal size in mm |
40, 50, 63 |
|
|
Accuracy class |
2.5 |
|
|
Scale ranges |
Welding engineering standard ranges for oxygen and acetylene to ISO 5171, as well as 0 ... 1 to 0 ... 400 bar to EN 837-1 |
|
|
Pressure limitation
|
Steady: 3/4 x full scale value Fluctuating: 2/3 x full scale value Short time: Full scale value |
|
|
Permissible temperature |
Ambient: -20 ... +60 °C Medium: +60 °C maximum |
|
| Temperature effect |
When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of the span |
|
|
Process connection |
Copper alloy NS 40: G 1/8 B (male), 14 mm flats NS 50,63: G 1/4 B (male), 14 mm flats |
|
Connection location |
Lower mount (LM) Centre back mount |
|
Pressure element |
Copper alloy , C-type or helical type |
|
Movement |
Copper alloy |
|
Dial |
Aluminium, white, black lettering |
|
Pointer |
Aluminium, black |
|
Case |
Steel, brass-coloured, with pressure relief in case back |
|
Window |
Polycarbonate, snap-fitted in case |
■ Other process connection
■ Case brass or stainless steel
■ Slip-on bezel
■ Back mount (BM)
■ Acetylene pressure gauge for pressure regulators for manifold systems per ISO 7291 (BAM tested)
